ASME B16.36 Orifice Flanges — Flow Measurement Assemblies

ASME B16.36 orifice flanges are used with orifice plates for differential-pressure flow measurement in oil & gas and chemical plants. Dimensionally identical to ASME B16.5 flanges (NPS ½–16, Class 300–2500) but include two radially drilled ½" NPT pressure tappings located 1" upstream and 1" downstream of the orifice plate, plus jack screws for plate removal under pressure.

Supplied in matched pairs with RTJ or RF facing. All tapping holes pressure-tested to 1.5× design pressure. Dimensional inspection report per API 2564 available. EN 10204 3.1 MTCs included. Export from Mumbai to oil & gas metering stations worldwide.

ASME B16.36 Duplex Orifice Flange Assembly Details

ASME B16.36 covers orifice flanges and associated orifice flange unions, used in conjunction with orifice plates for flow measurement in pressurised piping systems. B16.36 duplex and super duplex orifice flanges feature two 1/4" NPT pressure taps (one upstream, one downstream of the orifice plate) machined 1 inch from the orifice plate face per AGA-3 and ISO 5167 differential pressure measurement standards. All ASME B16.36 orifice flanges are supplied as a matched pair with jackscrew, jack bolt, and alignment pins, enabling removal of the orifice plate under pressure. Available in NPS 1 to 16 in Classes 300 to 2500 to ASTM A182 F51/F60/F53 material.

Feature	B16.36 Specification
Pressure tap size	1/4" NPT, one each upstream and downstream
Tap location	1" (25.4mm) from orifice plate face (corner taps available)
NPS range	NPS 1 to NPS 16
Pressure classes	300, 400, 600, 900, 1500, 2500
Facing	Raised face (RF) with spiral serrated finish (125–250 AARH)
Jackscrew	Supplied as standard on Class 300 and higher
Material	ASTM A182 F51 (S31803), F60 (S32205), F53 (S32750)

B16.36 Orifice Flange Applications

• Wellhead and separator inlet flow metering on oil and gas production platforms
• Custody transfer measurement in corrosive gas and condensate pipelines
• Flowmeter spool pieces in chemical plant feed and product piping
• Fiscal metering stations for high-salinity produced water disposal
• Reagent injection rate measurement in mining process plants
