PED Approved Duplex Pipe Exporter Manufacturer, Supplier & Exporter | Ragnar Metals & Tubes

• Direct manufacturer — Competitive mill prices
• ISO & third-party inspected — EN 10204 MTCs
• Export-ready packaging and global logistics

Request a Quote in 1 Hour

PED 2014/68/EU Approved Duplex Pipe — Pressure Equipment Directive Compliance

The EU Pressure Equipment Directive (PED 2014/68/EU) requires that pressure equipment placed on the EU market meets Essential Safety Requirements (ESRs) and carries a CE mark. duplex S31803 (EN 1.4462) pipe supplied to EU buyers for pressure equipment must include EN 10204 3.1 material test certificates, dimensional reports and, for Category III/IV equipment, notified body (NoBo) approval of the material's European Approval for Materials (EAM) or use of a listed material in a harmonised standard such as EN 13480-2 (metallic industrial piping).

Ragnar Metals supplies PED-compliant pipe with EN 10204 3.1 certificates from an accredited inspection body. We support EU fabricators with full documentation packages including EN 10216-5 or EN 10217-7 compliance, lot traceability, and REACH/RoHS declarations. Lead time for PED documentation 5–7 working days.

Duplex & Super Duplex Steel Grade Selection Guide

Selecting the correct duplex grade depends on the chloride concentration, temperature, H2S partial pressure, and design pressure of your application. Duplex 2205 (S31803/S32205) offers a PREN of 34–35 and handles chloride concentrations up to 1,000 ppm at temperatures up to 150°C. Super Duplex 2507 (S32750) with PREN 42 handles up to 35,000 ppm chloride (seawater) at temperatures to 220°C. For H2S sour service, both grades comply with NACE MR0175/ISO 15156 when hardness is maintained below HRC 28 (max HRC 32 per ASTM A890). Ragnar Metals and Tubes supplies a complete range of duplex and super duplex products to ASTM, ASME, EN, and ISO standards with full EN 10204 3.1 MTC and third-party inspection by SGS, TUV, or Bureau Veritas.

Grade	UNS Number	PREN	Max Chloride (ppm)	Key Standard	Use Case
Duplex 2101	S32101	26	200	ASTM A240	Mildly corrosive service, structural
Duplex 2205	S31803/S32205	34–35	1,000	ASTM A182 F51/F60	General oil and gas, chemical process
Super Duplex 2507	S32750	42	35,000	ASTM A182 F53	Seawater, deep offshore, sour service
Super Duplex Zeron 100	S32760	40	35,000	ASTM A182 F55	Offshore umbilicals, sour service

Duplex Steel Product Applications

• Offshore oil and gas production, processing, and export piping systems
• Desalination plants — reverse osmosis high-pressure trains and brine piping
• Chemical plant chloride and acid service pipework and pressure vessels
• Marine vessel seawater cooling, ballast, and fire-fighting systems
• Mining plant acidic slurry and leach circuit piping

About Ragnar Metals & Tubes

Ragnar Metals & Tubes is a trusted manufacturer, supplier, and global exporter of high-performance metal products including fasteners, fittings, pipes, tubes, flanges, and custom-engineered components. With a strong export presence in USA, UK, Germany, UAE, Saudi Arabia, Canada, Australia, and 50+ countries, we are known for delivering precision-engineered solutions for critical and high-temperature industrial applications.

Our manufacturing facility follows strict quality control systems with ISO 9001, ISO 14001, and ISO 45001 certification. Every product is tested and supplied with EN 10204 3.1 / 3.2 Material Test Certificates, ensuring complete material traceability and compliance with international standards such as ASTM, ASME, DIN, EN, and BS.

We cater to bulk industrial buyers, EPC contractors, and engineering projects across oil & gas, petrochemical, marine, power generation, aerospace, offshore drilling, and heavy engineering sectors. With flexible manufacturing, custom dimensions, and fast global delivery, we ensure reliable, consistent, and timely supply for all project requirements.

Why Choose Ragnar Metals & Tubes

• 50+ Countries served
• 24/7 RFQ Support
• Fastest delivery
• Direct manufacturer with bulk stock and fast lead times
• ISO 9001 certified production and documented QA
• Global shipping with export-grade packaging
• EN 10204 3.1 / 3.2 MTCs, third-party inspection on request
• Global export experience to USA, UK, EU, MENA & APAC
• Custom sizes and drawing-based manufacturing
• Faster quotations — send quantity, grade and dimensions
• Bulk quantity available at factory price
• 100% traceability with heat number stamping

Testing & Quality Inspection Process

At Ragnar Metals & Tubes, our testing process is designed to ensure the reliability, durability, and performance of every product we manufacture—including Pipes & Tubes, Fittings, Flanges, Sheets & Plates, Fasteners, and Rods & Bars. All testing follows internationally recognized standards such as ASTM, ASME, ISO, EN, and DIN.

Each batch undergoes multiple inspection stages starting from raw material verification to final dispatch. Our advanced laboratories perform chemical, mechanical, and non-destructive tests to ensure full compliance and traceability.

Types of Tests Performed

Ultrasonic Testing (UT)

Detects internal defects using high-frequency sound waves without damaging the material.

Hardness Testing

Checks resistance to deformation to ensure materials meet mechanical strength requirements.

Surface Finish Inspection

Examines surface quality, cracks, and finishing accuracy for high-precision applications.

Impact Test (Charpy V-Notch)

Measures impact resistance and toughness under varying temperature conditions.

Heat Treatment Report

Ensures optimal mechanical properties through controlled heating and cooling processes.

Tensile Test

Evaluates tensile strength, yield strength, and elongation to verify compliance with standards.

Quality Documentation & Traceability

Every batch is certified and supported with complete documentation including EN 10204 3.1 / 3.2 Material Test Certificates (MTC), heat number traceability, and third-party inspection reports (SGS, TUV, BV, Lloyds) upon request.

Our testing technicians are trained to follow strict procedures, ensuring that Ragnar Metals & Tubes maintains its reputation as a reliable global supplier trusted across the Oil & Gas, Petrochemical, Marine, Power, and Heavy Engineering industries.

Available Grades Table

PED Approved Duplex Pipe Exporter	Composition	Applications
2205 (Duplex)	22% Cr, 5% Ni, 3% Mo	Oil & gas, marine applications
2507 (Super Duplex)	25% Cr, 7% Ni, 4% Mo	Aggressive chloride environments
S31803 (Duplex)	22% Cr, 5% Ni, 3% Mo	Chemical processing, offshore oil
Super Duplex S32750	25% Cr, 7% Ni, 4% Mo	Marine, power generation
UNS S32760	26% Cr, 8% Ni, 4% Mo	Seawater applications, pulp and paper
31803	22% Cr, 5% Ni, 3% Mo	Petrochemical, oil & gas
F51 (Duplex)	21% Cr, 5% Ni, 2.5% Mo	Marine, chemical industries
F53 (Super Duplex)	25% Cr, 7% Ni, 3.5% Mo	Oil and gas, chemical processing

Specifications Table

Material	PED Approved Duplex Pipe Exporter
Grades	2205, 2507, S31803, S32750, UNS S32760
Standard	ASTM A312 / A213 / A269 / A358
Size Range	1/2" NB to 24" NB (Seamless), 1/2" NB to 100" NB (Welded)
Length	Single Random, Double Random & Custom Cut
Form	Round, Square, Rectangular

Chemical Properties Table

Element	2205 (%)	2507 (%)
Carbon (C)	0.03 max	0.03 max
Chromium (Cr)	22.0–23.0	25.0–26.0
Nickel (Ni)	4.5–6.5	6.0–8.0
Manganese (Mn)	2.0 max	1.0 max
Silicon (Si)	1.0 max	1.0 max
Phosphorus (P)	0.03 max	0.03 max
Sulfur (S)	0.02 max	0.02 max
Molybdenum (Mo)	3.0–4.0	4.0–5.0

Mechanical Properties Table

Property	2205	2507
Tensile Strength (MPa)	620 min	750 min
Yield Strength (MPa)	450 min	550 min
Elongation (%)	25 min	25 min
Hardness (HRB)	95 max	98 max

PED Approved Duplex Pipe Exporter Price List (2025)

Material Grade	Thickness	Price (USD / Kg)	Price (INR / Kg)
2205 (Duplex)	3 mm	$3.50 – $4.20	₹290 – ₹350
2507 (Super Duplex)	6 mm	$4.00 – $4.80	₹320 – ₹390
2205 (Duplex)	10 mm	$4.50 – $5.30	₹350 – ₹430

Note: The above prices are for reference only. Actual pricing may vary based on size, thickness, quantity, raw material cost, and delivery location. Contact us to get the best and most updated pricing for PED Approved Duplex Pipe Exporter.

Lead Time

2–7 weeks depending on size

Delivery Terms

FOB, CIF, DDP

Shipping Modes

Sea / Air / Express

Export Packaging & Shipping

• Sea-worthy fumigated wooden crates with waterproof lining
• Palletised boxing with clear shipping marks & heat number labels
• Container stuffing supervision and loading photos on request

MOQ & Payment Terms

Minimum Order Quantity: 25–100 Kg depending on part size and grade.

Payment Terms: Depending On Grade and Quantity Size

Applications & Uses

• Oil & Gas Industry
• Petrochemical Plants
• Water Treatment Plants
• Pharmaceutical Industry
• Food & Beverage Industry
• Automobile Industry

Cities We Suppllied In India

We exported to 50+ countries worldwide.

Frequently Asked Questions

Do you provide Material Test Certificates?

Yes, we provide EN 10204 3.1 / 3.2 Material Test Certificates with complete chemical and mechanical analysis for every shipment.

What is the Minimum Order Quantity (MOQ)?

MOQ generally ranges between 25–100 Kg depending on product size, grade and specifications.

Do you export to USA, Europe and UAE?

Yes, we ship worldwide including USA, UK, Germany, UAE, Saudi Arabia, Canada and Australia.

What are your payment terms?

Typical payment terms are 30% advance and 70% against copy of shipping documents. Payments via T/T, LC and SWIFT are accepted.

What packaging do you use for export?

All products are packed in sea-worthy fumigated wooden boxes with waterproof lamination, pallet loading and shipment marking for traceability.
